070411

Servo-Controlled 3-Way Vacuum Solenoid Valves, Servo-Control Pressure PSI (87-116), SOLENOID AND CONNECTOR SOLD SEPARATELY

Valve Type: 3 way valve
Port Size: G3/4"
Orifice Size: 20 mm
Max Capacity SCFM(cum/h): 23.5
Vacuum Level: 1"-29.53"Hg (0.5 to 1000)
Configuration: 3 way
Weight lbs(kg): 2.76
Additonal PDF:

*SOLENOID AND CONNECTOR SOLD SEPARATELY

$762.38 ea.

In Stock!

Quantity: Add

No CAD files available for this product

Coil Image
Item#: 00 07 03N
Compatible with Valve model: 070411
Product: Coil
Voltage: 12 Volts DC
Absorption: 16W
Duty Cycle: 100%
Weight: 0.22 (100) lbs(g)
$46.62 ea.
Dimensional
Drawing

Coil Image
Item#: 00 07 04N
Compatible with Valve model: 070411
Product: Coil
Voltage: 24 Volts DC
Absorption: 18W
Duty Cycle: 100%
Weight: 0.22 (100) lbs(g)
$46.62 ea.
Dimensional
Drawing

Coil Image
Item#: 00 07 256N
Compatible with Valve model: 070411
Product: Coil
Voltage: 24 Volts AC 50-60 Hz
Absorption: 16W
Duty Cycle: 100%
Weight: 0.22 (100) lbs(g)
$46.62 ea.
Dimensional
Drawing

Coil Image
Item#: 00 07 258N
Compatible with Valve model: 070411
Product: Coil
Voltage: 110 Volts AC 50-60 Hz
Absorption: 16W
Duty Cycle: 100%
Weight: 0.22 (100) lbs(g)
$46.62 ea.
Dimensional
Drawing

Connector Image
Item#: 00 07 63
Compatible with Valve model: 070411
Product: Coil Connectors
Operating Temp: -40 to +90
Cable: 6mm - 8mm
Weight: 0.053 lbs(g)
$8.23 ea.
Dimensional
Drawing

Connector Image
Item#: 00 07 101
Compatible with Valve model: 070411
Product: Coil Connectors
Operating Temp: 40 to +90
Cable: 6mm - 8mm
Weight: 0.053 lbs(g)
$23.04 ea.
Dimensional
Drawing

Connector Image
Item#: 00 15 157
Compatible with Valve model: 070411
Product: Coil Connectors
Operating Temp: -40 to +90
Cable: 6mm - 8mm
Weight: 0.02 lbs(g)
$24.42 ea.
Dimensional
Drawing

070411
