070320

2-way Vacuum Solenoid Pilot Valve, 2/2 NC, SOLENOID AND CONNECTOR SOLD SEPARATELY

Valve Type: 2 way valve
Port Size: G1/2"
Orifice Size: 12 mm
Max Capacity SCFM(cum/h): 6.0
Vacuum Level: 1"-29.53"Hg (0.5 to 1000)
Configuration: 2 way
Weight lbs(kg): 0.820
Additonal PDF:

*SOLENOID AND CONNECTOR SOLD SEPARATELY

$324.96 ea.

In Stock!

Quantity: Add

No CAD files available for this product

Coil Image
Item#: 00 07 03N
Compatible with Valve model: 070320
Product: Coil
Voltage: 12 Volts DC
Absorption: 16W
Duty Cycle: 100%
Weight: 0.22 (100) lbs(g)
$46.62 ea.
Dimensional
Drawing

Coil Image
Item#: 00 07 04N
Compatible with Valve model: 070320
Product: Coil
Voltage: 24 Volts DC
Absorption: 18W
Duty Cycle: 100%
Weight: 0.22 (100) lbs(g)
$46.62 ea.
Dimensional
Drawing

Coil Image
Item#: 00 07 256N
Compatible with Valve model: 070320
Product: Coil
Voltage: 24 Volts AC 50-60 Hz
Absorption: 16W
Duty Cycle: 100%
Weight: 0.22 (100) lbs(g)
$46.62 ea.
Dimensional
Drawing

Coil Image
Item#: 00 07 258N
Compatible with Valve model: 070320
Product: Coil
Voltage: 110 Volts AC 50-60 Hz
Absorption: 16W
Duty Cycle: 100%
Weight: 0.22 (100) lbs(g)
$46.62 ea.
Dimensional
Drawing

Connector Image
Item#: 00 07 63
Compatible with Valve model: 070320
Product: Coil Connectors
Operating Temp: -40 to +90
Cable: 6mm - 8mm
Weight: 0.053 lbs(g)
$8.23 ea.
Dimensional
Drawing

Connector Image
Item#: 00 07 101
Compatible with Valve model: 070320
Product: Coil Connectors
Operating Temp: 40 to +90
Cable: 6mm - 8mm
Weight: 0.053 lbs(g)
$23.04 ea.
Dimensional
Drawing

Connector Image
Item#: 00 07 186
Compatible with Valve model: 070320
Product: Coil Connectors
Operating Temp: -40 to +90
Cable: 6mm - 8mm
Weight: 0.053 lbs(g)
$30.21 ea.
Dimensional
Drawing

070320
